Heald 25A-24" Rotary Surface Grinder
Heald Rotary Surface Grinding Machine
Electromagnetic Chuck Diameter: 24"
Swing Inside Chuck Pan: 26-3/4"
Standard Wheel Size: 18" x 2" x 8"
Wheel Spindle Speed: 1285 RPM
Distance Top of Chuck to Center Wheel, max.: 13-3/4"
Distance Top of Chuck to Center Wheel, min.: 7"
Maximum Angle, Convex: 15 degrees
Maximum Angle, Concave: 5 degrees
Wheel Slide Speeds: 0 - 20 FPM
Overall Dimensions: 8' x 5' x 6' Tall
Approx. Weight: 9,000 lbs.
10 HP Spindle Drive Motor: 220/440/3/60
All Items Subject to Prior Sale
Be Sure to Verify Specs & Condition Prior to Purchasing
