Tek DSA601 DSA602 DSA601A DSA602A service manual

Tek DSA601 DSA602 DSA601A DSA602A service manual

THESE SCANS ARE BOOKMARKED IN GREAT DETAIL
TABLE OF CONTENTS and THEORY of OPERATION section
ALL ELECTRONIC PAGE NUMBERS MATCH THE ORIGINAL MANUAL PAGE NUMBERS
(i.e. 2-1,2-2,2-3, etc. NO MORE GUESSSING WHERE YOU ARE)
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out. I get a lot of inquiries about scanning these at full size (11X17). Very few of us however have a printer that will handle this size paper, and if you print a 11x17 scan "shrink to fit" on 8.5 x 11 you cant read the schematic info.
