Tornado infra red soldering station

Tornado infra red soldering station

Monochrome series model :ZH-130S36M-O M-Sound source of
Harmonious music O Orange G Green B-Blue
Color series model:ZH-130C34V C 8colors(red,green,blue,indigo,violet,yellow,white and black)
Outisde diameter of screen:130mm
Horizontal pixels:160(color),180(monochrome)
Internal memory for display:4M(equivalent to 20000 chineses charactes or 3000 standard pictures)
Maximum settable number of subjects:6400
Format of cartoon:Repetition cycle 1~255
Interface for communication with computer:standard serial interface(COM1 port).For portable computer
with no COM1 port,USB may be used for relaying to COM1 port.
Mode of communication:38400-baud half-duplex
Permissible erasing times of Flash reservoir:About 1000
Sound source of back ground music:12 harmonious Love music compositions
Capacity of loudspeaker:Greater than 300MW
Power supply:220V/50HZ or 110V/60HZ
Overall dimensions:140mm(L) 140mm(W) 180mm(height)
The spectral power density of the pre heater is shown in the graph below
Maximum permissible temperature 900 ? C
Lifetime ? more than 3000 hours
Super high temperature radiators were developed to increase the previous maximum possible surface rating
of ceramic panel radiators from 64 kW/m? to 77 kW/m?.
These radiators, produced using the hollow casting ceramic process, are filled with thermal insulation material
and have a special black glaze and a gold-plated back. At an operating temperature of 900 ?C, over 75 % of the
electrical energy supplied is transferred to the material to be heated as medium to long-wave IR radiation.
Series radiators are therefore particularly suitable for use in plant construction in which special solutions have to
Concerning spectral power distribution refer to the following drawing
The Radiator and Radiant heating up curves are as shown below
What is a ceramic infrared radiator?
Ceramic IR radiators are electrical heating elements consisting mainly out of a technical ceramic being
What is the application for an ceramic heating element?
IR heating elements are used for an endless number of heating and drying applications. A selection
of IR heating and drying applications has been placed on our Website under applications. For determining
if electric heating elements can be used for your application we provide consulting and test devices. If required
we can do heating and drying tests in our laboratory, too.
Which advantages does an electric infrared heater have?
Electric IR heaters have among others the following advantages:
Long service life due to an embedded heating coil.
Surface is clean and does not oxidise.
What is the wavelength of an ceramic infrared emitter?
electric IR emitters provide only the non-visible infrared radiation and no visible or rather hardly visible light.
The emitted infrared radiation covers the medium and long-wave infrared range of 2 - 10 m.
Does an infrared radiant heater fulfill clean room requirements?
Yes. For decades IR radiant heaters have been used in clean rooms class 100 or better. They are used in
semiconductor production, in the pharmaceutical industry and in manufacturing picture tubes. Infrared Radiators
are also used in the production of modern TFT displays.
What is the optimal distance between infrared radiators and good to be heated?
In the case of heat-sensitive goods (paper, thin foils) the radiation distance should not be less than 50 mm.
If the radiators are not mounted densely next to each other, the distance must be larger if the goods to be heated
are stationary. If the distance between radiators is 3 - 4 cm, a distance between radiators and goods of 15 - 20 cm
is required in order to achieve uniform heating.
Can infrared radiant heating elements be used to heat metals?
Bright metal shows a relatively weak absorption of infrared radiation. However, corroded, roughened, coated, enameled
or painted metal can reach an absorption degree of more than 90%.
Are infrared heaters susceptible to splash water?
When hot, infrared emitters are splash resistant. If the radiators get in touch with water when they are cold, they must
subsequently dry at a low temperature (max. 80?C) for a few minutes.
Infrared radiation elements are successfully used in warming cabins and therapeutic equipment. The heat radiation
emitted by Radiators has healthy effects. Risks are not known.
Some people need to take an ERSA rework station for 5000-6000 Euro, some other a Jovy for 2000
Euro, and again other people take a Tornado Indra Station or in many cases the 250$
TORNADO INFRA HANDHELD and DO THE SAME JOB !!! At the end it depends all on the SKILLS OF
THE PERSON THAT WORK with the rework station.
So, everybody can use whatever suits him most, and what he can afford.
* The product send from China directly to the user by DHL with the leadtime 3-5 days after collected by China DHL.
* The price are NOT included the import duty nor VAT, the receiver need to be responsible on own
* Return policy: within 7 days upon the receiving of the product & please specify us the reason of returning. The replacement
or full refund would be implemented from us.
