Tektronix PS5010 PROGRAMMABLE POWER SUPPLY
plug-in for the popular TM5000 series of modular test equipment.
Tektronix manual: part# 070-3391-00.
Covers operations, service, theory of operation (hyper linked to the schematics), calibration and adjustment (hyper-linked to the appropriate adjustment location pictorials), parts lists, board layouts and schematic diagrams, programming information A total of 213 pages in 65MB in PDF format.
THE TABLE OF CONTENTS, THEORY of OPERATION & CCALIBRATION
Sections are all HYPER-LINKED.
If that’s not enough for you the electronic page numbers now match the actual manual page numbers as well!
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white (Schematics you can READ!)
Schematics and board overlays with color notes: 256 colors 600dpi
Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out.
