50Tn HYDRAULIC PRESS, Pressmaster CFP-50
50Tn HYDRAULIC PRESS, Pressmaster CFP-50
50 TON PRESSMASTER C-FRAME HYDRAULIC PRESS
TONS OF FORCE ......(MAX).................... 50 TONS
RAM SPEED (IPM).....(APPROACH/PRESS)......... 198/50
(IPM).....(RETURN)................. 243
TABLE ..............(LR X FB)................ 26" X 14"
TABLE THICKNESS ............................. 4" Thick
U-SLOT WIDTH ................................ 4"
UPPER PLATEN (L-R)........................... 20"
UPPER PLATEN (L-R)........................... 12"
DAYLIGHT .................................... 18"
STROKE ADJUSTABLE ........................... 12"
THROAT ...................................... 12"
FLOOR TO TABLE .............................. 36"
FRONT TO BACK................................ 54"
HEIGHT (OVERALL)............................. 92"
WIDTH ....................................... 29-1/2"
MOTOR HP @ 1760 RPM ......................... 15 HP
208-230/460/575 VOLTS, 3 PH, 60 CYCLE
- RAM TRAVEL IS GUIDED BY PRECISION-GROUND GUIDE RODS
- DUAL ELECTRIC PALM BUTTONS FOR OPERATOR SAFETY
- PROGRAMMABLE CONTROL SYSTEM (PCS)
- LOW SPEED TEFC BALDOR ELECTRIC MOTOR
- MFG. IN NORTH AMERICAN FROM US & CANADIAN COMPONENTS
O.A. 46"L X 60"W X 102"H, WT. 8,000#
- PRESSURE REVERSAL SWITCH .....................$400
- DUAL CONTROL-YOUR CHOICE OF USING PALM BUTTONS OR FOOT
- AIR OR WATER COOLER FOR PRODUCTION WORK
- T-SLOTTING FOR BOLSTER OR UPPER RAM PLATE.....$10/INCH
- CUSTOM DESIGNS AVAILABLE - WE BUILD THEM YOUR WAY!
Machine Location: HARRISON, NJ
