The Stainless Standard in Washdown-Duty
Washguard Stainless Steel Duck
All we have is The Motor Itself
Volt: 208-230/190 Volt: 460/380
F.L.A. 3.1-3/2.6 F.L.A. 1.5/1.3
PH 3 S.F.A. 3.5-3.3/3 S.F.A. 1.65/1.5
Ser. Fact. 1.15 Insul. Class F4 HZ 60/50
H.P. 1/.75 Duty Cont Code K Design B Encl. Tenv
R.P.M. 1725/1425 Frame 56C Nema Nom.Eff. 8.5 P.F. 77 IP Code 55
Leeson Washguard Motors. For use with most milk pump receiver units.
Leeson introduces a new line of Stainless Steel SST Motors designed for long life in demanding washdown applications. The Leeson Electric Washguard SST Stainless Steel Motors line was developed by Leeson Electric in response to the recent appearance in the North American market of lesser quality imported Stainless Steel Motors claiming, "premium features without a premium price".
WASHGUARD,C Face Less Base, TENV, Premium All-Stainless,56C-145TC
The new Leeson Stainless Steel Motors are tough to withstand the severe washdown environments. Leeson Stainless Steel Motors' all exterior components frame, base, endshields, fan guard, shaft, hardware, conduit box and cover are made from 300 series stainless steel for maximum corrosion resistance. Nameplate data is permanently laser-etched into the motor frame no Mylar nameplate that can wash off or riveted metal nameplate to trap dirt. No paint or any type of coating is used on the exterior of the Leeson Washguard motors. Leeson Electric's Washguard SST Stainless Steel Motor offers features above and beyond these other motors and at a competitive price. A detailed feature comparison is available in Leeson Electric's Bulletin 1520.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
