SigmaSeries High Frequency Switch
~ TESTED IN A SUMMATION TESTFRAME - FULLY FUNCTIONAL ~
In an ATE system, it is usually necessary to connect instruments to a variety of points. The HFS10 provides this capability by taking advantage of the SigmaSeries architecture. Through the High Frequency bus, the HFS10 can connect one of six external lines to either the Waveform Recorder (WFR10), Function Generator (FNG10) or Univeral Counter Timer (UCT10). The Digital Multimeter can (DMM10) can also be connected to any of the six signals through the High Accuracy bus.
* DC – 200 MHz signal switching
* 6 channel external signal routing
* 11 TestFrame bus connections
* Multiplexer for other modules
* Expandable to 138 channels
P/N: 1700-104485 Rev. A (9000-102089)
~ International: *International Surface Parcel (4-6 weeks) or XpressPost International (5-8 Business days) - $39.95 & $69.95 respectively
PHOTOS BELOW ARE OF THE ACTUAL MODULE
