Panavise combination model 381

Panavise combination model 381

The 381 Vacuum Base PanaVise is a combination of the 380 Vacuum Base and the 303 Standard Head. This Vise is excellent for portable applications. A half turn of the rubber base activation lever will attach the unit to any smooth, non-porous surface.
Single knob controls the head movement through three planes: 90 degree tilt, 360 degree turn and 360 degree rotation
Jaws are 2.5” (63.5 mm) wide, 0.5” (12.6 mm) tall and open to 2.25“ (57.1 mm)
Nylon jaws offer excellent electrical insulation and gentle holding power [continuous heat tolerance up to 200 degrees F (93 degrees C), intermittent heat to 300 degrees F (149 degrees C)]. Interchangeable jaws available
Pad foot print measures 5.125” (130.2 mm) by 4.25” (108 mm)
Overall height: 6.125” (155.6 mm)
