EscrowUnlt © AP6.0MAZAK MODEL MICRO-CENTER H-10 4 AXIS TWO PALLET
CNC HORIZONTAL MACHINING CENTER
CAME RIGHT FROM SERVICE FROM A LARGE PLANT AND WILL GO RIGHT BACK
USED TO RUN LOW VOLUME PARTS FOR THEIR PRODUCT
Pallet Table Size: 17.7" x 17.7"
Table Travel, Right And Left (X Axis): 22"
Spindle Head Travel, Up And Down (Y Axis): 15.75"
Saddle Travel, In And Out (Z Axis): 15.75"
Index Table: 72 Positions In 5 Degree Increments
Distance From Spindle Center To Table Top: 1.97" - 17.72"
Distance From Spindle Nose To Table Center: 3.94" - 19.68"
Spindle Nose Taper: ISO No. 40
Spindle Diameter At Front Bearing: 2.76"
Spindle Speed Range/Number Of Speeds: 3976 (Full Auto.)
Number Of Tools/Selection Method: 24/Random
Maximum Tool Diameter/Length: 3.15"/13.78"
When Adjacent Pockets Are Empty: 5.9" Diameter
Maximum Tool Weight/Tool Clamping Force: 17.6 Lbs./1,980 Lbs.
Table Load Capacity/Clamping Force: 800 Lbs./ 4,400 Lbs.
Ballscrews (X, Y And Z Axes): 1.42" Diameter, 0.394" Load
Main Drive/Power Requirements: 10 HP/22 KVA
(Currently Wired For 460 Volts)
Copy Of Operating Manual And Maintenance
New Price Of Current Model Today:
Model HCN-4000, 15.75" x 15.75" Pallet: $220,000.00 USD
Model HCN-5000, 19.68" x 19.68" Pallet: $249,000.00 USD
Approximate Dimensions Of Machine: 14' x 7' 6" x 7' 10" H
Approximate Weight Of Machine: 19,300 Lbs.
Approximate Dimensions Of Chiller: 18" x 24" x 48" H
Approximate Weight Of Chiller: 430 Lbs.
Approximate Total Weight: 19,730 Lbs.
bed type of trailer, not an enclosed truck.)
