SP230ACP sipex +5V rs-232 multi-chnl drivers/receivers

SP230ACP sipex +5V rs-232 multi-chnl drivers/receivers

The SP230A Series are multi–channel RS-232 line drivers/receivers that provide a variety of configurations to fit most communication needs, especially where ±12V is not available. Some models feature a shutdown mode to conserve power in battery-powered systems. Some require no external components. All, except one model, feature a built-in charge pump voltage converter, allowing them to operate from a single +5V power supply. All drivers and receivers meet all EIA RS-232D and CCITT V.28 requirements. The Series is available in plastic DIP and SOIC packages.
* Operates from Single +5V Power Supply
* Meets All RS-232D and V.28 Specifications
* Improved Driver Output Capacity for
* WakeUp Feature in Shutdown Mode
* 3–State TTL/CMOS Receiver Outputs
* ±30V Receiver Input Levels
* Low Power CMOS – 5mA Operation
* Wide Charge Pump Capacitor Value
