The Tektronix 115 Pulse Generator is a solid state, stable and versatile instrument. It has a maximum repetition rate of 10 mHz, a maximum amplitude of plus or minus 10 volts, and a minimum rise- and fall-time of 10 ns. Controllable pulse characteristics are repetition rate, width, amplitude, risetime, falltime, DC offset, and polarity. It has five modes of operation, which are undelayed pulse, delayed pulse with calibrated delay, paired pulses, an externally triggered burst of pulses, and an externally gated burst of pulses. In addition to the output pulse, there is an undelayed and delayed trigger output.
Specifications: Download a manual from http://bama.edebris.com/manuals/tek/115/
This unit is covered by 30-DAY RETURN AND my 1-year warranty. See warranty page for details and limits.
Unit comes with a power cord (built in), and a photocopy printed manual.
If you have any questions or would like additional pictures please email me at R_horn@rockford-industrial.com
Tektronix 115 Pulse Generator producing P=100 usec, W=50 usec, RT/FT=10usec
Tektronix 115 Pulse Generator producing P=100 usec, W=50 usec, RT/FT=10ns
Tektronix 115 Pulse Generator producing P=100 ns, W=50 ns, RT/FT=10ns
Tektronix 115 Pulse Generator effect on 50 ns pulse of adjusting fall time (FT)
Tektronix 115 Pulse Generator effect on 50 ns pulse of adjusting rise time (RT)
Tektronix 115 in gated burst mode, driven by 114. Lower trace, gating from 114.
Upper trace, bursts of pulses from 115 during gating + excursion. Sweep speed .2ms.
As above, but scope set to .5ms sweep.
Tektronix 115 set to 5usec pulses.
Notes on testing: This unit has been completely tested and is guaranteed. The specifications all require the unit to be terminated in a 50 ohm load.
