DRILL GRINDER, Giddings &Lewis HC EXACTAMATIC
DRILL GRINDER, Giddings &Lewis HC EXACTAMATIC
1) Preowned GIDDINGS & LEWIS (BICKFORD) Semi-automatic drill point Grinder
Model HC Exactamatic, New 1978
Drill point type and capacities:
conventional point 1/16” to 1 ½” diameter
helical point 1/16” to 1” diameter
racon point 1/16” to 1” diameter
split point 1/16” to ½” diameter
pyrcon (four facet) 1/16” to 1” diameter
Grinding wheel size 12” diameter x 5” bore x ¾” face
Drill point included angles from 90° to 140°
Capability to handle all types of 2-fluted, right hand drills
Lip clearance angle adjusted from the operatorÂ’s control console
Point angle varied from by angular adjustment of workhead
Cam action-generated rotary motion in all three axes set at the operatorÂ’s control console
Built-in cam-formed wheel dresser
(5) wheels mounts with (15) wheels
(6) quick-change bushing index plates
(20) rubber flex collet holders with (8) extra flex collets from 1 1/64” to 1 ½” diameter capacity
(33) Quick-change drillholder sleeves from 1 1/64” to 1 ½” diameter capacity
Aget Mistkop oil mist collector with stand
1 H.P. grinding wheel drive motor and electrical controls
3/60/575 volt controls with transformer for 3/60/230 or 460 volt input
Approximate weight: 1,200 lbs.
